Single door wall cabinet

Products > Network Cabinet > Single door wall cabinet
    • 1

Single door wall cabinet

Model: YX-007
◇ Doublesection wall mount rack
◇ Framestructure. Max loading 60kg
◇ TheFrame Can be moved According to Requirement

Features:
◇ Doublesection wall mount rack
◇ Framestructure. Max loading 60kg
◇ TheFrame Can be moved According to Requirement
◇ Walland stand installation type, optional caster and support feet for standinstalling
◇ Quickopen side door with lock easy to install and maintain, back door can chooseright or left close
◇ Topand bottom wire path

◇ Optional120mm axial motor 1 piece or 2 pieces

Parameter

MODEL NO.

CAPACITY

WIDTH(MM)

DEPTH(MM)

HEIGHT(MM)

PACKING DIMENSION

W/M

D/M

H/M

YX-007-6406

6U

600

450

368

0.62

0.47

0.39

YX-007-6606

600

600

0.62

0.62

0.39

YX-007-6409

9U

600

450

501

0.62

0.47

0.52

YX-007-6609

600

600

0.62

0.62

0.52

YX-007-6412

12U

600

450

635

0.62

0.47

0.66

YX-007-6612

600

600

0.62

0.62

0.66

YX-007-6415

15U

600

450

769

0.62

0.47

0.79

YX-007-6615

600

600

0.62

0.62

0.79

YX-007-6418

18U

600

450

901

0.62

0.47

0.92

YX-007-6618

600

600

0.62

0.62

0.92

YX-007-6422

22U

600

450

1082

0.62

0.47

1.1

YX-007-6622

600

600

0.62

0.62

1.1

YX-007-6427

27U

800

450

1304

0.62

0.47

1.32

YX-007-6627

800

600

0.62

0.62

1.32

Applications
◇ FTTx (ODF rack)
◇ Optical fiber cabinet
◇ Optical fiber network
