Fiber Optic fast connector 06

Products > Optical Passive Series > Fiber Optic fast connector 06

Model: FOFC-SC/PC-06
Fiber Optic fast connector, Product length:51mm,Single mode or Multi mode,G.652D, G657A, Drop cable.Indoor cable

Product Structure：

Measured the Structure

Product length：

50mm ≤L≤60mm(≈51m)

Ptical Characteristics：

Category	Specification
Aoolicablefor	Drop cable.Indoor cable
Fiber mod	Single mode or Multi mode
Fiber type	G.652D, G.657A2,
Fiber cable	3.0*2.0mm rubber-insulated optical cable ∅3.0/∅2.0 /∅0.9 insulated optical cab
Fiber diameter	0.125mm
Force holds 2 x 3mm cable type at the beginning the fast connector	≥ 45 N, loss ≤ 0.3 dB (sample cable length:3Mtest time: 2 minutes
Fiber lock	Lock holds fiber reliability, bears hang force ≥ 3.8 N, attenuation changes ≤ 0.2 dB
Working wavelength	1310 nm, 1490 nm, 1550 nm
Operation time	S	About 50(no fiber cut)
Insertion Loss	dB	≤0.35
Insertion Loss Typical value	dB	0.3
Return Loss	dB	UPC≥50, APC≥55
Fastening strength of naked fiber	N	≥3
Tensile strength	N	≥45
Reusable	Time	≥10 time
Operating Temperature		-40~+85
On-line tensile strength（20N）	dB	ΔIL≤0.3
Mechanical durability (500 times)	dB	ΔIL≤0.3
Drop-off test (drop-off height4m, once per direction, totally 3 times)	dB	ΔIL≤0.3

Environmental performance requirements:

Category	Specification
Category	Condition	IL Variation	RL Variation	Appearance
High TEMP	85℃, 96H	≤0.3	≤5	No mechanical da mage, like deform ation, cracking and untight
Low TEMP	-40℃, 96H	≤0.3	≤5
Temperature Cycle	Cycle: 8 hours Total: 12 cycles / 96 hours Temperature Maintenance: 1 hour	≤0.3	≤5
Temperature/ Humidity	85℃, 95%RH, 96H	≤0.3	≤5
Immersion	25℃, 96H	≤0.3	≤5
Salt Mis	5% Nacl, 6.5＜PH＜ 7.5,35℃,96H	≤0.3	≤5

Mechanical Performance Requirement

Category	Specification
Category	Condition	IL Variation	RL Variation	Appearance
Impact	Height: 4m; 1 drop each axis; 3 cycles	≤0.3	≤5	No mechanical da mage, like deforma tion, cracking and untight
Vibration	Frequency: 10 ～ 50HZ; Sweep: 45 times / min; amplitude: 0.75mm; Duration:30min each axial	≤0.3	≤5
Torsional	Pull：15N; The distance between Loading location and fast connector: L = 22-28cm; Rate：10times / min. Times:	≤0.3	≤5
Tensile	Pull：50N; The distance between Loading lo cation and fast connector: L =3M; Duration:1min	≤0.3	≤5
